FT232 USB 2.0 to TTL RS485 Serial Converter
It is designed audio interface,and used for microphone or audio signal cable .
It is voltage chip,the voltage is wide and stability
It is convenient for set frequent and input signal with five buttons
The input audio signal amplitude adjustment and microphone sensitivity adjustment
Heavy bass boos
Specifications:
Size:37*26*6 mm
Working voltage:DC 3V-5V
Working current: about 35MA
Color: red
Net weight: 7 g
Application:
FM wireless microphone audio stereo - forwarding FM radio small power.
Package Include:
1* FM Radio Transmitter Module
Features:
Support devices with RS485 interface: surveillance cameras, video capture device, fingerprint attendance machine, PBX, CNC machine, microcontroller, etc.
Specifications:
Standard: USB2.0 standard, backward compatible, in line with the standard RS485
Direction control: the use of automatic data flow control, auto distinguish and control data transfer direction
Baud rate:300-9216000bps, automatically detecting the serial signal data rate
Load capacity: support multipoint, each converter allows RS485 interface device to connect 32
Interface Protection: TVS tube protection, USB self-recovery protection
Support Windows98/ME/2000/XP/WIN7/Vista, Linux, Mac
Color: green
Size: 75*18*14mm
Net weight: 15 g
Package Include:
1* USB to TTL/RS485 Converter Adapter Module
