RFID Reader ID-2 (125 kHz)
This is a compact and easy to use RFID reader module.
The ID-2 is a smaller module requiring an external antenna.
Hook up an antenna, power the module,
hold up a card, and you'll get a serial string output containing the unique ID of the card.
מאפיינים:
- 5V supply
- 125kHz read frequency
- EM4001 64-bit RFID tag compatible
- 9600bps TTL and RS232 output
- Magnetic stripe emulation output
מידות:
19x21mm
תיעוד:
Datasheet
